1. The following will study and analyze the onboard power supply weight of DJI FC30 tethered UAV system:
1. Influence of power weight on flight performance
Affects takeoff weight: The weight of the onboard power supply directly affects the takeoff weight of the UAV, which in turn affects its flight performance, including climb rate, flight speed and endurance. The FC30 tethered power supply designed and manufactured by Maiuway is all aluminum alloy and weighs only 6.5kg in total, which is 42% lower than the original battery 11kg, thus significantly improving the payload of the FC30 UAV. For the FC30 that needs to carry a specific mission payload, more applications can be expanded.
Impact on flight stability: Weight distribution has a significant impact on the flight stability of UAVs, and the weight and distribution of onboard power supply need to be carefully designed to maintain flight stability. The power supply designed and manufactured by Maguway, imitating the original battery design, and cooperating with the lower load, can achieve a balance of center of gravity with the original battery, improving flight stability.
Structural strength: If the onboard power supply is too heavy, the structural parts of the UAV must have enough strength and stiffness to support the additional weight.
Space layout: The weight and volume of the power supply need to be properly arranged inside the drone to avoid impact on other systems.
2. The influence of power supply weight on the application field
Emergency response: In the area of emergency response, the weight of the onboard power supply can impact the ability of the UAV to rapidly deploy and evacuate.
Environmental monitoring: For environmental monitoring missions that require long flights, lighter power supplies help extend the drone's endurance and reduce the risk of the drone's motor overheating.
3. The influence of power supply weight on safety
Flight safety: If the weight of the power supply is excessive, it may create additional risks during flight, especially in extreme weather conditions.
Intelligent development: The reduction of the weight of the tethered power supply can provide space for the UAV to carry more intelligent devices and sensors, and promote its development in the direction of intelligence.
In summary, the onboard power supply weight of the DJI FC30 tethered UAV system has an important impact on its performance, safety, application fields and future development direction. Therefore, the research on the weight of the airborne power supply is not only related to the optimization of the technical level, but also closely related to the overall design concept and market competitiveness of the UAV. Through continuous technological innovation and material research and development, Maiuway is expected to achieve a further reduction in the weight of the power supply, thus opening up a broader space for the application of the FC30 tethered UAV.
2. 30kW（including 240m tether cable）tether drone station
3.Original battery design onboard power supply
4. Technical data
5. MYUAV FC30 tethered system highlights
1. The base station uses the well-known power supply in the industry, and the isolation circuit design ensures the safety of high-voltage transmission
2. The base station only adopts the international standard 1000Vdc scheme, which is mature and reliable
3. The base station adopts redundant load design to ensure stable long-term power supply and long-term flight safety
4. The on-board power supply adopts ultra-precision voltage regulator circuit design, and the constant voltage regulator accuracy is ±1.5%, which is higher than the industry level
5. The onboard power supply is designed to be the same as the original battery. Replace a battery, plug our power and play
6. The onboard power supply adopts patent rain proof design, cooperating with FC30 UAV, fearless of wind and rain
7. The onboard power supply can work at full power for a long time, without derating or burning the machine
