MYUAV Communication Tethered Power System For Drones 10kw 500V DC / 750V DC
Place of Origin:
China
Brand Name:
myuav
Minimum Order Quantity:
1
Price:
1500usd
Packaging Details:
case
Delivery Time:
14 working days
Payment Terms:
T/T
Inquiry Now
Get A Quote
Specifications
Highlight Features
Communication Tethered Power System
,Tethered Power System
,Tethered Power System For Drones
Power:
10kw
Input:
380V AC
Output:
750V DC
Size:
240mm×85mm×398mm
Weight:
8kgs
Product Description
MYUAV 10kw 500V DC/750V DC Tethered Drone Power for Communication
input
380V AC
output
10kw 500V DC/750V DC
240mm×85mm×398mm
8kgs
communication
CAN
The specified tethered power system is designed to convert AC power to DC power and features the following characteristics: Input: 380V AC Output: 750V DC Power Output: 10kW These specifications indicate a high-power DC output for a tethered drone system.
Let's consider some significant aspects associated with this type of power supply system:
1. Conversion Efficiency: The efficiency of the power conversion process is crucial to minimize losses and ensure effective utilization of the electrical input. High efficiency ensures optimal power delivery to the drone system.
2. Tethered Drone Applications: Tethered drone systems typically utilize ground-based power sources to supply continuous electrical power to the drone, enabling extended flight times and prolonged mission durations for tasks such as surveillance, telecommunications, and industrial inspections.
3. Electrical Safety: Operating at high power levels requires strict adherence to electrical safety standards to ensure the safety of operators, equipment, and the environment. The system should feature suitable protective measures and conform to relevant safety regulations.
4. Compatibility and Integration: The power supply system needs to be compatible with and seamlessly integrate into the tethered drone system, ensuring effective communication and control interfaces to manage and regulate the power supply during drone operations.
5. Electrical Infrastructure: Given the input voltage requirement of 380V AC, a robust and suitable electrical infrastructure is necessary to provide the required input power to the system. This includes compliance with electrical codes and standards.
Overall, the described power supply system is intended to provide continuous high-power DC output to a tethered drone. It's critical to ensure that the system meets safety requirements, complies with relevant regulations, and provides the necessary power for prolonged and uninterrupted drone operations.
