MYUAV Tethered Drone All Purpose Uav Loaded With High Brightness Searchlight For Drone Use Rescue

Product Details

Load type: Drone searchlight
Weight: 1200±10g
Size: 158*156.4*213
FOV: 16.7°
Power supply voltage: 40v-80v
Rated power: 200W

▲ Maximum power: 300W (maximum time 1min)
▲ Light Angle: ≤16℃

Luminous flux: extremely bright 30000lm±3%(power: 300W)/ Long bright: 20000lm± 3%(200W)
Luminous efficiency: 100lm/W (Power: 300W)
Spot diameter: 15m(distance: 50M)/ 30m(distance: 100M)
Search area: 176㎡ (distance: 50M) /706㎡ (distance: 100M)
Function mode: Long bright/very bright/flash
Head rotation Angle: Pitch: -110°~+45°/ level: ±175°
Head design range: Pitch: -207°~+90°/ horizontal: ±175°/ roll: ±90°

▲ At least 3 loads can be compatible with the same app control

【 Product Overview 】 :

Designed to enhance the nighttime operation and emergency rescue capabilities of drones, this all-in-one UAV searchlight is an efficient accessory that can significantly increase the nighttime field of view and achieve accurate lighting. Suitable for major mainstream UAV brands, including but not limited to DJI, Clairvoyant aviation, etc., easily installed on the bottom or side of the UAV, through the PTZ control system to achieve accurate positioning and remote control.

【 Core technology 】 :

1. ** High brightness LED light source ** : The use of advanced LED technology, light source brightness up to 20,000 lumens, providing ultra-long distance, ultra-high brightness lighting effect, effective irradiation distance up to 400 meters, to ensure clear identification of the target in the dark.

2. ** Intelligent PTZ control ** : Integrated professional PTZ system, supporting 360° all-round rotation and smooth pitch Angle adjustment, to achieve flexible lighting guidance, can automatically adjust the lighting Angle according to the change of UAV attitude, to ensure that the required area is always illuminated.

3. ** Multi-mode lighting ** : Provide a variety of lighting mode switching such as focus, flood light, as well as remote brightness, color temperature irradiation Angle control function, to meet different operational needs, such as search and rescue, inspection, terrain mapping, accident investigation, etc.

4. ** Long endurance and high efficiency heat dissipation ** : built-in high efficiency battery, with energy-saving drive circuit, to ensure long-term operation needs; At the same time, the use of integrated heat dissipation design, effectively reduce the heat source, extend the service life.

5. ** Harsh environment adaptability ** : With waterproof, dustproof and impact resistance design, up to IP67 protection level, to ensure stable operation in a variety of complex weather and tough environment.

【 Application Scenario 】 :

- Night search and rescue operations
- Night inspection of industrial facilities
- Night monitoring of forestry, farmland and nature reserves
- Landform mapping and geological exploration
- Night law enforcement and emergency response in the field of public security such as public security and fire protection

【 Compatibility and Service 】 :

This UAV searchlight is widely compatible with many UAV models on the market, and provides professional installation guidance and technical support services. To ensure customer satisfaction, we are committed to providing a comprehensive after-sales service, including but not limited to product quality assurance, operational training, and quick response troubleshooting assistance.

---

With the purchase of this drone searchlight, you will receive a powerful tool to upgrade your drone operations and break the boundaries of day and night, helping you broaden your vision in the dark, improve your work efficiency, and ensure the success of your operations.

FAQ

Q1: What is the main function of UAV searchlight?

A1: The UAV searchlight is mainly used to enhance the visual ability of the UAV at night or under low light conditions, which is suitable for various scenes such as search and rescue, security monitoring, infrastructure inspection, agricultural plant protection, geographic mapping, film and television shooting, etc., to provide high-intensity and long-distance lighting support to facilitate the discovery, tracking and recording of the target.

Q2: Is this searchlight compatible with my drone model?

A2: Our drone searchlights are designed to be compatible with most major drone brands and models on the market, such as DJI series, Yuneec, Parrot, etc. Please confirm the specific model and check with our customer service team to ensure the best compatibility.

Q3: What is the brightness and illumination distance of the searchlight?

A3: The brightness of the UAV searchlight is usually measured in lumen (lumen), different models will vary, some advanced searchlights can provide up to thousands of lumens of brightness, irradiation distance can reach hundreds or even thousands of meters. For details, refer to the product specification table.

Q4: How long does the searchlight last?

A4: Battery life depends on the power of the searchlight, battery capacity, and the drone's own power management system. Generally speaking, a fully charged high-performance battery can support the continuous work of the searchlight for about half an hour to about 1 hour, and the actual use time also needs to consider the overall load and flight speed of the drone.
