IP65 Commercial Multicopter Drone Waterproof 10kg Loading 6 Rotor 12S
Place of Origin:
China
Brand Name:
myuav
Certification:
MD-7
Model Number:
MD-7
Minimum Order Quantity:
1
Packaging Details:
case
Delivery Time:
7 working days
Payment Terms:
T/T
Inquiry Now
Get A Quote
Specifications
Highlight Features
Commercial Multicopter Drone
,IP65 Multicopter Drone
,Commercial Drone Waterproof
Type Of Aircraft:
Six-rotor
Frame Material:
Industrial Nylon + Carbon Fibre
Arm Storage:
Umbrella Folding
Vehicle Wheelbase:
1290mm
Battery Compartment Height From Ground:
460mm
Pitch:
2490mm
Net Weight:
11kg
Maximum Take-off Weight:
22kg
Battery:
6S 6000mAh*2
Maximum Wind Resistance:
13m/s
Mapping Protocol:
Figure 1
Communication Distance:
7km (no Mask)
The Graph Transfer Point:
2.4 GHz
Operating Temperature:
-20—60℃
Positioning System:
Dual GPS/RTK
Positioning Accuracy (GPS):
≤ 0.5m
Positioning Accuracy (RTK):
≤ 0.3m
Maximum Flight Speed:
25m/s
Maximum Creep Speed:
10m/s
Maximum Lowering Speed:
6m/s
Maximum Angular Speed:
120°/s
Maximum Flight Angle:
30°
FPV:
Standard
Dual-GPS:
Standard
Remote Control With Screen:
Standard
RTK:
Optional
Nacelle:
Optional
Avoidance Radar:
Optional
Shout:
Optional
Searchlight:
Optional
Drop Box:
Optional
Thrower:
Optional
Mount Mode:
Standard Quick Disconnect
Net Battery Weight:
4.6 Kg
Waterproof Bodywork:
IP65
Product Description
Multicopter Commercial Drone 10kg Loading 6 Rotor 12S
Features:
- 5-way loads can be supported at the same time
- Up to 10kg
- Front FPV lens
- 12S power system
- The battery is mounted with quick-release rails
- Modular, one-piece chassis
Specification Parameters:
| Basic parameters for a drone with 10kg load | |
| Parameters | |
| Type of aircraft | Six-rotor |
| Frame material | Industrial Nylon + Carbon Fibre |
| Arm storage | Umbrella folding |
| Vehicle wheelbase | 1290mm |
| Battery compartment height from ground | 460mm |
| Pitch | 2490mm |
| Net weight | 11kg |
| Maximum take-off weight | 22kg |
| Battery | 6S 6000mAh*2 |
| Maximum wind resistance | 13m/s. |
| Mapping protocol | Figure 1 |
| Communication distance | 7km (no mask) |
| The graph transfer point | 2.4 GHz |
| Operating temperature | -20—60℃ |
| Positioning system | dual GPS/RTK |
| Positioning accuracy (GPS) | ≤ 0.5m |
| Positioning accuracy (RTK) | ≤ 0.3m |
| Maximum flight speed | 25m/s. |
| Maximum creep speed | 10m/s. |
| Maximum lowering speed | 6m/s. |
| Maximum angular speed | 120°/s. |
| Maximum flight angle | 30° |
| FPV | Standard |
| Dual-GPS | Standard |
| Remote control with screen | Standard |
| RTK | Optional |
| Nacelle | Optional |
| Avoidance radar | Optional |
| Shout | Optional |
| Searchlight | Optional |
| Drop box | Optional |
| Thrower | Optional |
| Mount mode | Standard quick disconnect |
| Net battery weight | 4.6 kg |
| Waterproof bodywork | IP65 |
